| Model |
1218/1225/1235/1245 |
1625/1635/1645 |
2025/2035/2045 |
| Table Size (mm) |
1000 X 1800/ 2500/ 3500/ 4500 |
1300 X 2500/ 3500/ 4500 |
1700 X 2500/ 3500/ 4500 |
| Tabel Stroke (mm) |
2000/ 2700/ 3700/ 4700 |
2700/ 3700/ 4700 |
2700/ 3700/ 4700 |
| Width between Columns (mm) |
1200 |
1600 |
2000 |
| Table Feed (mm/min) |
0- 5000 |
0- 5000 |
0- 5000 |
| Table Rapid (mm/min) |
10000 |
10000 |
10000 |
| Height under Spindle (min/max)
(mm) |
200-700 |
200-950 |
200-1200 |
| SPINDLE |
| Spindle Taper |
BT-50 |
BT-50 |
BT-50 |
| Spindle Power (kw) |
9/11, 11/15 |
15/18 |
18/22 |
| Spindle Speed (rpm) |
100- 4000 |
100- 4000 |
100- 4000 |
| Maximum Cutter Dia (mm) |
125 |
125/160 |
160 |
| system |
Siemens |
802 D SL |
802 D SL |
802 D SL |
| Optional |
| Siemens |
828 D |
828 D |
828 D |
| Siemens |
810 D |
810 D |
810 D |
| Fanuc |
Oi |
Oi |
Oi |
| Standard Accessories |
|
Optional Accessories |
|
| 4000 rpm spindle |
|
Linear scale feedback system |
|
| Auto lubrication system |
|
Full splash guard |
|
| Spindle air curtain |
|
Coolant through spindle |
|
| Machine light |
|
NC rotary table |
|
| 3 Tier light |
|
NC rotary cum tilting table |
|
| Flushing coolant |
|
6000/ 8000 rpm spindle(refrigeration type
cooling of spindle |
|
| Electrical panel with heat exchager |
|
Right angle head |
|
| Absolute encoder for poitioinig feedback |
|
Spindle mounted probe |
|
| Rigid tapping |
|
Table mounted probe |
|
| Hydraulic counter balance of
head |
|
Oil mist |
|
| Power draw bolt |
|
Voltage stabilizer |
|
| MPG |
|
Ultra isolation transformer |
|
| Telescopic cover for X-axis |
|
|
|
| Bellow for Y & Z-axis |
|
|
|
| Linear motion guideways system |
|
|
|
| Leveling bolts, blocks |
|
|
|
| Operation manual, maintenance
manual, electrical & circuit diagram |
|
|
|
